THÔNG SỐ KỸ THUẬT:
Chức năng đo : Phát hiện phase (dương, âm), kiểm tra dây
Giải điện áp : 70 ~ 600VAC (50/60Hz) Sine ware
Kích thước kìm kẹp : 2.4mm ~ 17mm
Hiện thị :
+ Phát hiện pha thuận : 4 LED sáng theo thứ tự thuận chiều kim đồng hồ và 3 tiếng bíp kêu
+ Phát hiện pha Ngược : 4 LED sáng theo thứ tự ngược chiều kim đồng hồ và 3 tiếp bip kêu
Kích thước : 70 mm W × 75 mmH × 30 mm D
Khối lượng : 200 g
Chiều dài dây : 0.7m(27.56 in)
Phụ kiện : Hộp đựng, Pin, Đầu kẹp
Bảo hành : 12 tháng
Hãng sản xuất : Hioki
Xuất xứ : Nhật
| Measurement Function |
Phase detection (positive,negative),live wire check (R-S/S-T only) |
| Voltage Detection Method |
Electrostatic induction method |
| Voltage Range |
70 to 600V AC (50/60Hz)(sine wave,continuous input) |
| Clamp Diameter |
2.4mm(0.09in) to 17mm(0.67in) of insulated wiring |
| Display |
| Phase Detection : |
Positive ; |
4 LEDs lit in clockwise order and 3 short beeps |
| |
Negative ; |
4 LEDs lit in counterclockwise order and one continuous beep |
| Live Wire Check : |
R-S and S-T lamps will light if voltage between wires are within voltage range |
|
| Battery Check Function |
ON lamp blinks to indicate battery low status when instrument is turned on |
| Auto Power Off |
Auto shut off if no activity is detected after power is turned ON for 15 minutes |
| Power supply |
Two AA size batteries × 2 (rated voltage:DC3.0V; maximum rated ower:300mVA) |
| Continuous Use |
approx.70 hours (standby) |
| Dimensions, mass |
70 mm (2.76 in)W × 75 mm (2.95 in)H × 30 mm (1.18 in)D, 200 g (7.1 oz),
Cord length : 0.7m(27.56 in) |
| Accessories |
Carrying case(1), strap(1), R6P manganese batteries(2), spiral tube(1) |
